XYX系列轮式液压岩芯钻机

一、XYX系列轮式液压岩芯钻机简介 Introduction to XYX Series Wheel Hydraulic Core Drilling Rig XYX系列轮式液压岩芯钻机是为满足野外勘探短距离移场的需求，在常规液压钻机的基础上加装了可拆卸行走机构和拖挂装置的钻机。根据客户特殊要求，可定制两轮或四轮拖挂样式。 XYX series wheeled hydraulic core drilling rig is designed to satisfy the change of short distance construction site in field exploration. On the basis of hydraulic drilling rig, removable walking mechanism and towing device are installed. According to the special requirements of customers, we can customize two-wheel or four-wheel towing style. 二、XYX系列轮式液压岩芯钻机特点 Features of XYX Series Wheel Hydraulic Core Drilling Rig 1.配置可拆卸行走机构和拖挂装置，钻机短距离移场更方便。 Walking mechanism and towing device make it more convenient to move in short distance. 2.选配移机装置，可实现钻机主机的前后移动，便于井口操作。 The optional moving device can realize the front and back movement of the main machine and is convenient for wellhead operation. 3.选配电启动柴油机，降低操作者的劳动强度，特别是寒冷季节启动更便利。 The optional electrically started diesel engine can reduce the labor intensity of operators, especially in cold season. 4.具有油压给进机构，提高钻进效率。 It has an oil pressure feed mechanism to improve drilling efficiency. 5.配有孔底压力表指示压力，便于掌握孔内情况。 Equipped with hole bottom pressure gauge, easy to master the situation in the hole. 三、XYX系列轮式液压岩芯钻机参数Parameters of XYX Series Wheel Hydraulic Core Drilling Rig 钻机型号Drilling rig model XYX-100 XYX-150 XYX-200 整机参数Overall machine parameters 钻孔深度Drilling depth 100m 150m 200m 开孔直径 Open hole dia 325mm 325mm 400mm 终孔直径 End hole dia 75mm 75mm 75mm 钻杆直径Drill pipe dia 42mm 42/50mm 42/50mm 钻孔倾角Drilling angle 90°-75° 90°-75° 90°-75° 钻机重量Weight 500kg 550kg 1300kg 立轴 Vertical shaft 立轴转速Vertical shaft speed 142、285、570r/min 1010、790、470、295、140r/min 64、128、287、557r/min 立轴行程Vertical axis travel 450mm 450mm 450mm 卷扬机winch 单绳提升力Single rope lifting force 1000kg 1600kg 2400kg 单绳升降速度Lifting speed 0.42、0.84、1.68m/s 1.05、0.66、0.31m/s 0.41、0.82、1.64m/s 钢丝绳直径Wire rope dia 12mm 12mm 12mm 钢丝绳容量Wire rope capacity 35m 35m 35m 钻塔 Rig tower 有效高度 Effective height 6.5m 6.5m 6.5m 额定负荷Rated load 18T 18T 18T 泥浆泵Mud pump 类型type 卧式单缸双作用Horizontal single cylinder double acting 卧式单缸双作用 Horizontal single cylinder double acting 卧式单缸双作用 Horizontal single cylinder double acting 排量Displacement 95L/min 160L/min 160L/min 工作压力work pressure 1.3Mpa 1.3Mpa 1.3Mpa 进水管直径Inlet hose dia 50mm 50mm 50mm 出水管直径Outlet pipe diameter 32mm 32mm 32mm 注：产品不断改进，如有变动恕不另行通知，请以实物为准。 Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
