XYC系列车载式液压岩芯钻机

一、XYC系列车载式液压岩芯钻机简介 Introduction to XYC Series Vehicle-mounted Hydraulic Core Drilling Rig XYC系列车载式液压岩芯钻机是为满足野外勘探高速高效、机动性强和便于长短途移场的要求而设计的一种配置车载式底盘和液压钻塔的钻机，该钻机可实现工地内机动作业和长短距离转场。 XYC series truck-mounted hydraulic core drilling rig is a kind of drilling rig equipped with truck-mounted chassis and hydraulic derrick, which is designed to meet the requirements of high speed, high efficiency, strong maneuverability and convenient long-distance and short-distance migration in field exploration. 二、XYC系列车载式液压岩芯钻机特点 Features of XYC Series Vehicle-mounted Hydraulic Core Drilling rig 1.钻机塔架采用液压起落式自动伸缩钻塔，操作方便安全高效。 Drilling rig adopts hydraulic lifting automatic telescopic derrick, which is easy to operate, safe and efficient. 2.采用车载底盘，便于机动作业和长短距离移场。 Truck-mounted chassis is convenient for mobile operation and long-distance and short-distance field shifting. 3.底盘配置液压支腿，可用于钻机找平。 Chassis equipped with hydraulic legs can be used for leveling drilling rig. 4.采用24V电启动柴油机，降低操作者的劳动强度，特别是寒冷季节启动更便利。 The 24V electric starting diesel engine reduces the operator's labor intensity, especially in cold season. 5.配置BW-160泥浆泵，压力高，流量大，保证钻进深度及钻孔口径。 BW-160 mud pump has high pressure and high flow rate, which ensures drilling depth and borehole diameter. 6.配置移机装置，可实现钻机主机的前后移动，便于井口操作。 Configuration of the moving device can realize the front and back movement of the main machine and facilitate the operation of the wellhead. 三、XYC系列车载式液压岩芯钻机参数Parameters of XYC Series Vehicle-mounted Hydraulic Core Drilling Rig 钻机型号Model XYC-200A XYC-200 性能参数 Performance parameters 钻孔深度 Drilling depth 200m 200m 开孔直径 Open hole dia 400mm 400mm 终孔直径 End hole dia 75mm 75mm 钻杆直径 Drill pipe dia 42/50mm 42/50mm 钻孔倾角 Drilling angle 75-90° 75-90° 配套动力 Matching power 16.2kW 16.2kW 重量 Weight 3200kg 5000kg 钻机尺寸(L*W*H)Dimension 4.2*1.7*2.3m 6*1.9*2.7m 立轴Vertical shaft 立轴转速Vertical shaft speed 64/128/287/557r/min 64/128/287/557r/min 立轴行程Vertical axis travel 450mm 450mm 立轴最大扭矩 Vertical shaft maximum torque 2200N.m 2200N.m 立轴最大加压力 Thrust Maximum pressure of vertical shaft 40kN 40kN 立轴最大提升力 Maximum lifting force of vertical shaft 60kN 60kN 卷扬机Winch 单绳提升力 Single rope lifting force 1600kg 1600kg 单绳提升速度 Single rope lifting speed 0.12-0.95m/min 0.12-0.95m/min 钢丝绳直径Wire rope dia 12mm 12mm 钢丝绳容量Wire rope capacity 35m 35m 底盘Chassis 类别Category 农用三轮车 Agricultural tricycle 轻卡 Light truck 钻塔Derrick 有效高度Height 6.5m 6.5m 额定负荷Rated load 18t 18t 泥浆泵Mud pump 额定负荷Rated load 160L/min 160L/min 最大压力Max.Pressure 1.3MPa 1.3MPa 往复次数Times 165/min 165/min 吸水管直径Inlet hose dia 50mm 50mm 出水管直径Outlet hose dia 32mm 32mm 注：产品不断改进，如有变动恕不另行通知，请以实物为准。 Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
