PREALPINA COMPLETE RECYCLING LINE, from scraps to pellets

PREALPINA RECYCLING LINE 250 kg/h depending on material for PE PP EPS ABS PC PS etc constructed in 1996 reconditioned 2010 (gearbox) 2016 complete reconditioning (screw 100% capacity) Including : Loading conveyor belt 550 mm. wide x 4000 mm long with metal detector soundproof cased 550 mm. Grinder, 35 Kw motor complete with soundproof blowing vent kw 2,5 Stainless steel storing silo for reground scraps, capacity 3,5 m3 with min/max level indicator, paddle agitator, loading cyclone ith powder sleeve filtering system horizontal dosing auger to forced feeding unit forced feeding unit with conical forcing screw, driven by gearbox controlled by inverter with back/forth movement (in case of overfeeding) single screw 85 mm extruder 35 L/D, with Ansaldo d.c. 75 kw (09 Hp) motor, degassing unit with 2,5 kw vacuum pump, gearbox new in 2010, with gearbox forced lubrication group. Ceramic heaters cooled by vents automatic hydraulic screen changer diam 140 mm. screens Dynisco pressure control 2,5 kw hydraulic power station die face pelletizer, water cooled. Cutting group driven by a.c. 1, Hp motor with inverter. Adjustable knives-holding piece to control pellets length n.1 spare knif-holding shaft n.2 spare extruding nozzles classifier and drying centrifuge with eater collecting tank, heat exchange unit and a.c. 2,2 kw water recycling pump hopper electrical cabinet for management of 10 heating areas, Kloeckner & Mueller drive for extruder Total installed power 190 kw can be seen running for a dry test
