Double Ribbon blender

Double Ribbon blender Main Introduction: The Horizontal Screw Belt Blender is a new type, high efficiency mixing equipment, are widely used in food and chemical industry. Main features: 1. Horizontal tube body, inner & outer dual screw with special structure, running stable, best quality, low noise, long life, convenient installation, widly usage, with many kind of Blender structure, multiple function 2. Whole machine except for motor is made of stainless steel 3. With warm sheet, bearing great pressure, make easy-forming material into difficult forming after filling steam 4. For different mixing requirements, use different screw structure, rapid & thorough mixing 5. There is a split window in the body for cleaning 6. Load coefficient large, covering small surface 7. With safety screen inside cover 8. Pneumatic discharge door. Technical parameters: ModelSLD200SLD300SLD500SLD1000SLD1500Effective Volumeliters200L300L500L1000L1415LCubic foot7.110.617.735.350Total volume in cubic foot1015255066All Volume in liters280L420L710L1420L1887LBlend time0-30 min0-30 min0-30 min0-30 min0-30 minOverall Dimension(m)1.3×0.68×1.41.4×0.78×1.531.64×0.94×1.81.96×1.13×2.02.38×1.24×1.85Total Power in KW2.2 kw3 kw5.5 kw7.5 kw11 kwPower in unit HP3HP4HP7.5HP10HP15HPPower Supply3 Phase 208-415V 50/60Hz
