ARC系列空气反循环钻机

一、ARC系列空气反循环钻机简介Introduction to ARC Series Air Reverse Circulation Drilling Rig ARC系列空气反循环钻机是一种新型、高效、环保的地质钻探设备。它采用了巨匠研究院最新的空气反循环钻采技术，利用压缩空气作为循环介质，通过反循环方式将岩屑从孔底快速排出，岩屑粉尘通过集尘器有效收集整理，避免样本污染，确保了样本数据的准确性。该钻机主要用于矿产勘探、水文地质调查、工程地质勘察等领域，适用于各种地理环境，包括高海拔地区空气稀薄、永冻层较厚、地下水丰富等复杂环境，是地质勘探钻孔及其他深孔作业的首选设备。 ARC series air reverse circulation drilling rig is a new, efficient and environmentally friendly geological drilling equipment. It uses the latest air reverse circulation drilling technology from Master Research Institute, compressed air is used as the circulating medium to quickly discharge，the cuttings from the bottom of the hole through reverse circulation. Rock cuttings and dust are effectively collected and sorted through dust collectors，avoid sample contamination，ensure the accuracy of sample data. The drilling rig is mainly used in mineral exploration, hydrogeological exploration, engineering geological exploration and other fields, suitable for various geographical environments，including complex environments such as thin air at high altitudes, thick permafrost, and abundant groundwater. It is the preferred equipment for geological exploration drilling and other deep hole operations. 二、ARC系列空气反循环钻机特点Features of ARC Series Air Reverse Circulation Drilling Rig 1.高效钻探：空气反循环钻机采用密闭式循环系统，快速排出岩屑，减少重复破碎，显著提高钻进速度。 Efficient drilling: The air reverse circulation drill uses a closed circulation system to quickly discharge cuttings, reduce repeated crushing, and significantly increase drilling speed. 2.样本品质高：通过空气反循环钻探获得的岩屑粉尘样本不受污染，样品易于分类和追踪，能够准确定位矿化位置。 High sample quality: The rock chip dust samples obtained through air reverse circulation drilling are free from contamination, easy to classify and track, and can accurately locate the mineralization location. 3.绿色环保：使用压缩空气作为循环介质，相比传统的泥浆钻机，施工过程中无需大量水和化学药剂，减少了对环境的污染。 Green and environmentally friendly: Using compressed air as the circulating medium, compared with traditional mud drilling rigs, it does not require a large amount of water and chemicals during the construction process, reducing pollution to the environment. 4.全液压操作：钻架举升、动力头回转和给进、钻杆接卸等动作全部由液压系统实现，大幅降低了劳动强度，提高了施工效率。 Full hydraulic operation: drilling rig lifting, power head rotation and feeding, drill rod connection and unloading and other actions are all realized by the hydraulic system, which greatly reduces labor intensity and improves construction efficiency. 5.维护成本低：空气反循环钻机结构简单，关键部件采用高强度材料制造，耐磨性和抗腐蚀性强，减少了易损件的更换频率，维护成本低。 Low maintenance cost: The air reverse circulation drilling rig has a simple structure, and key components are made of high-strength materials with strong wear resistance and corrosion resistance, which reduces the replacement frequency of wearing parts and has low maintenance costs. 6.动力可靠：采用大品牌柴油机，动力强劲，性能稳定，售后服务完善。 Reliable power: adopt big brand diesel engine, strong power, stable performance and perfect after-sales service. 三、ARC系列空气反循环钻机参数 Parameters of ARC Series Air Reverse Circulation Drilling Rig 钻机型号Drilling rig model ARC-200 ARC-300 ARC-500 ARC-800 ARC-1200 整机参数Overall machine parameters 整车重量 Vehicle weight 6T 7.5T 9.5T 17T 23T 运输尺寸 Shipping dimensions 6000*1750*2350mm 6750*2200*2550mm 6750*2200*2650mm 10500*2250*3300mm 11500*2250*3400mm 底盘 Chassis 工程钢制履带 液压行走底盘Engineering steel tracks Hydraulic walking chassis 工程钢制履带 液压行走底盘Engineering steel tracks Hydraulic walking chassis 工程钢制履带 液压行走底盘Engineering steel tracks Hydraulic walking chassis 工程钢制履带 液压行走底盘Engineering steel tracks Hydraulic walking chassis 工程钢制履带 液压行走底盘Engineering steel tracks Hydraulic walking chassis 履带接地长度 Track ground length 2150mm 2500mm 2500mm 7000mm 8000mm 履带底盘宽度 Track chassis width 1700mm 1800mm 1800mm 2250mm 2250mm 液压高支腿 Hydraulic high outriggers 4 4 4 4 4 整机动力 Machine power 玉柴四缸柴油机Yuchai four-cylinder diesel engine 玉柴六缸柴油机Yuchai six-cylinder diesel engine 康明斯六缸柴油机Cummins six-cylinder diesel engine 潍柴六缸柴油机Weichai six-cylinder diesel engine 潍柴六缸柴油机Weichai six-cylinder diesel engine 主机功率Host power 77.3kW 110kW 132kW 176kW 220kW 技术参数Technical parameters 适用岩石强度Applicable rock strength F=6~20 F=6~20 F=6~20 F=6~20 F=6~20 钻杆直径 Drill pipe diameter Φ89/Φ102 Φ89/Φ102/Φ114 Φ89/Φ102/Φ114 Φ102/Φ114/Φ127 Φ102/Φ127/Φ146 钻孔直径 Drilling diameter 95-254mm 95-350mm 95-350mm 105-550mm 105-800mm 钻孔深度 Drilling depth 200m 300m 500m 800m 1200m 钻杆长度 Drill pipe length 1.5/2/3m 1.5/2/3m 1.5/2/3m 3/6m 6m 一次性推进长度One-time advancement length 3.6m 4m 4m 6m 6m 进尺效率 Footage efficiency 10-35m/h 15-35m/h 15-35m/h 10-35m/h 10-35m/h 回转扭矩 Rotary torque 5300-7600N.m 6200-8500N.m 8500-12000N.m 9000-18000N.m 12000-24000N.m 动力头提升力 Rotary torque 15T 22T 22T 47T 57T 卷扬机提升力 Winch lifting force 1T 2T 2T 2.5T 2.5T 爬坡角度 Climbing angle 30° 30° 30° 21° 21° 行走速度 Walking speed 2.5km/h 2.5km/h 2.5km/h 5km/h 6.4km/h 注：产品不断改进，如有变动恕不另行通知，请以实物为准。 Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
