5 Ton Mining Hydraulic Dump Tricycle for Metal Mine

5 Ton Mining Hydraulic Dump Tricycle for Metal Mine

original price: 2 800 USD
Xiangtan, China
Minimal order:
1 Set
Production capacity:
1000 Set / Year
Xiangtan, China
Anonymous
+86 17369222201
Ben Zhang
Contact person

Basic Information

Model Number YT-50
Power > 800W
Certification CE
Body Type Open
Brand Name Yutong
Place of Origin China
Driving Type Electric
Use For Cargo
Mining electric tricycle can transport ore, clean up slag, transport tools, personnel, etc. in the mine tunnel. Electric dump trucks have no heat, no smoke, no noise, and no pollution, which brings good news to the miners who are suffering from the smoke and fire of diesel locomotives and maintain the air quality in the roadway. Three-layer craftsmanship of the whole vehicle, original headlights, and mirrors. Multi-layer tires, heavy beams, thicker carriages, and suspended rear axles. Easy to drive, flexible direction, heavier chassis, no skidding. (Customized carriages according to the size of the roadway) is a battery transportation tool used by factories or mines to transport raw materials, semi-finished products, finished products, ore, slag and other materials.

Delivery terms and packaging

Model YT-50 Carriage volume 1.9m³ Loading Capacity 5000kg Unloading height 2350mm Loading Height 1250mm Min ground clearance ≤250mm Min turning radius ≤4900mm Gradeability (heavy load) ≤6° Maximum lift angle of carriage 45° Tyre model Front tire 600-10 Rear tire 700-16 Damping system Main frame: 9 pieces*10mm, sub frame: 6 pieces*10mm Operation System steering wheel Light System FRONT AND BACK LED LIGHT Max Speed 25km/h Motor Power 7.5kw Cargo box size (outer diameter) 2200*1400*600mm Container board thickness 3mm Voltage 72V120AH Quantities of Battery 6 piece,12V120AH Maintenance free Dimensions 3800*1400*1550 Frame welding Weight 1500kg Control system Inbol Controller Wheelbase 1400 mm
Port: Guangzhou
Срок доставки: 15 days
Package Type: Not packaged or unpackaged
Weight Incl. packaging: 1500 Kilogram
Packing size: 380x140x155 Centimeter
